Mini stack isokinetic sampling digunakan untuk menangkap gas polutan dari cerobong seperti halides, ammonia, serta hidrogen sulfide.

MST-17 menggunakan absorben tertentu yang digunakan untuk menangkap gas polutan yang berasal dari pembakaran pada cerobong asap. Sifat gas yang homogen, maka pengambilan sampling mengikuti pengambilan sampling traverse point sesuai pada metode isokinetik.

Brand: CBI-Tech

Type: MST-17

[wptab name=’Spesifikasi’]

Suction Pump:

• Pump : KNF VAC, 15 Lpm
• Diaphragm Vacuum Pump : Free flow 15 lpm, ryton head, EPDM Diaphragm and vales 230v

Gas Meter:

• Qmax : 2.5 m3/h
• Qmin : 0.016 m3/h
• Sensitive flow rate : 0.003 m3/h
• Pmax : 10 kPa
• Max index vol : 9999 m3

Nozel:

• Nozel Set : Stainless Steel
• Size : 4, 6, 8, 10, 12, 14, and 16 mm
• Including : Three 5/8 inch tube nuts

Probe:

• Linear Glass 36″, 8 mm
• Pyrex liner with 12/5 Ball Joint

Pitot type S Tube:

• Pitot Tips Extend, SFA-47 SS
• Offset Replacement Pitot Tip 3/8″ SS Extended for Use with method 5 Nozzle and SFA-47

Filter:

• Stainless Steel Adapter Filter Assembly 47mm, 5/8TU
• Method 17 SS in-Stack Filter unit, 5/8″ tube union
• Uses 47 mm diameter Filter Element

Impinger Set:

• Glass Impinger 25 mm (10 pcs)
• Includes : Stainless Steel Clamp adaptor and Box hold for impinger

Pipe Probe:

• Stainless Steel Sheath Mini Probe Heated
• 3/4 ” Diameter
• 36 inch Long
• Stainless Steel pipe probe 5/8″ x 150 mm (1 pcs)
• Stainless steel pipe probe 3/8″ x 150 mm (1 pcs)

Heater:

• In Heater probe 220 VAC, 0.9 meters with cables electical plug

Complete Unit:

• Display, TC, PNL, LED 220V
• 10 feet Flexible Thermocouple Extention
• Controller Novus Temp RED LED
• Connector Ungrout 12/5 Sockets
• Manometer Molded plastic range 0-80 mm red oil 826 sp. gr.
• Swith TC 7 Channel
• Gage minihelic, 0 – 100 mm H2O
• Quick Connect Bulkead 1/4″ to 1/4″ tube union female SS
• Stainless steel tube union 3/8″
• Flowmeter 1-20 liters with valve
• Glass Fiber Filter Paper Diameter 47 mm (100 sheet/box)
• Carrying Case

[/wptab]

[end_wptabset]

Untuk harga: hubungi kami melalui kontak yang tersedia pada website ini.
